Full Size yet Portable and Easy to Disassemble
Increased weight capacity up to 330 lb.
Two (2) U1 Batteries Standard with Wireless Removal
Operating range up to 18 miles per charge
Comfort Spring Suspension for a smoother ride
Ultra Bright LED headlight standard
Ultra Bright LED Tail Light standard
Charging port below the control panel
4-inch ground clearance
Red and Blue Shroud panels included free
Disassembles quickly and easily for transport
Description:
EX
Medicare Code:
Not Coded
Weight capacity:
350
Drive Wheels:
Rear
Maximum speed:
5 MPH
Operating range:
18 MILES
Ground clearance:
4"
Turning radius:
54"
Batteries:
U1
Colors:
Blue, Red
Features:
90 Amp Dynamic R Series Controller, Electro-Mechanical Brakes, Electronic Speed Control, Freewheel Mode
Charger:
Off Board
Length:
44"
Width:
22"
Height (ground to top of back of seat):
35"-37"
Ground to Top of Seat:
22.75"-24.75"
Ground to Top of Deck:
6.75"
Deck to Top of Seat:
16"-18"
Number Seat Height Positions:
3
Size of Increments:
1”
Front Axle to Rear Axle:
34.7"
Weight w batteries:
161 LBS
Front half weight:
53 LBS
Rear half weight:
36 LBS
Seat weight w arms:
23 LBS
Batteries Weight:
24 lbs. per pack
Heaviest piece:
53 LBS
Front tire:
9"
Rear tire:
9"
Rear Anti-Tippers:
2"
Standard Seat:
Stadium Style
Seat Back Height – no headrest:
16”
Seat Width x Depth:
18" x 16"
Seat Color:
Black Vinyl
Optional Seat:
Stadium Style
Optional Seat Back Height – no headrest:
16”
Optional Seat Width x Depth:
20” x 18”
Optional Seat Color:
Black Vinyl
Warranty Frame:
Lifetime
Warranty Drive Train:
2 Year
Warranty Electronics:
2 Years
Warranty Batteries:
1 Year
