provided during consultation.
| Product Width | Mast Base & Boom Assembly 64 lbs. Power Pack 5 lbs. Base Assembly (not incl. battery) 33lbs. Boom (not incl. battery) 31 lbs. |
| ProductLength/Depth | Maximum 51″ Minimum 49″ |
| Product Height | Maximum 71″ Minimum 23″ |
| Product Weight Capacity | 340 lbs. |
| Folded Dimensions | |
| Batteries | 12 volt rechargeable sealed lead acid type |
| Battery Capacity | 3.2 ampere hours |
| Charger Rated Input | 230Vac 50/60Hz |
| Charger Rated Output | 27.4/29.0 VDC@0.8A |
| Electrical Shock Protection | Charger – Class II Lift – Internal Power Source |
| Degree of Shock Protection | Charger – Type B Lift – Type B |
| Spreader Bar Dimensions | Max. Height 5′ 4.5″ Min. Usable Height 1′ 3″ Height @ Max Reach 3′ 9″ Reach @ Max Height 2′ 4″ Reach @ Min Height 1′ 7″ Max. Reach 2′ 9″ Turning Radius 3′ 5″ |
| Leg Dimensions | Open External Width 42.5″ Open Internal Width 39.5″ Closed External Width 25″ Closed Internal Width 22″ Overall Height of Legs 4.5″ |
| Front Twin Casters | 3.3″ |
| Rear Braked Casters | 4″ |
| ling Use Type | Hoyer Grey Looped |
Exceptionally Versatile No-tools folding design allows for compact storage
Oversized Handle The oversized handle provides a large surface area, from which the caregiver can maneuver the lift before use.
Design The triangular fold design ensures two very important functions. (1) The lift stands unaided when being stored or transported. (2) The lift can be safely left with the knowledge that it will not become unstable while not in use.
Footpad The push footpad has been designed to reduce the force needed to initiate movement when maneuvering the stationary lift in a forward direction
